NEEV calibration columns are designed for determining and verifying pump flow rates.
Calibration is performed on a periodic basis and after every maintenance job on pump.
NEEV calibration columns are easily instaled at pump suction to provide fast, easy, and economical means of checking pump flow rate.
Calibration columns are avaliable in 14 standard sizes.
Customization is always an option. we design and fabricate calibration pots according to client requirements.
| VOLUME (ML) |
PUMP FLOW (L/H) |
| 50 | 3 |
| 100 | 6 |
| 250 | 15 |
| 500 | 30 |
| 1000 | 60 |
| 1500 | 90 |
| 2000 | 120 |
| 4000 | 240 |
| 5000 | 300 |
| 6000 | 360 |
| 8000 | 480 |
| 10000 | 600 |
| 17000 | 1020 |
| 20000 | 1200 |
| 30000 | 1800 |
| 35000 | 2100 |
| 50000 | 3000 |
THE ABOVE STANDARD SIZES ARE RECOMMENDED FOR CALIBRATING PUMP FLOW RATES SHOWN BASED ON A 60 SECOND CALIBRATION TIME.
